Brand New Spare Parts for GEA Westfalia Separator
As China's leading manufacturer of disc separators since 1954, Huading Separator provides high-quality spare parts for GEA Westfalia separators and disc stack centrifuges.
Technical Specifications
| Parameter |
Specification |
| Drive |
Gear / Belt |
| Bowl Speed |
4000 - 10000 rpm |
| Centrifugal Force |
> 10,000 g |
| Bowl Volume |
8 - 300 L |
| Bowl Weight |
50-15000 Kg |
| Solids Holding Space |
2 - 50 L |
| Inlet Pressure |
0-0.1 Mpa |
| Liquid Outlet Pressure |
0.2-0.6 Mpa |
| Starting Time |
5 - 30 mins |
| Stopping Time (no brakes) |
> 40 mins |
Company Overview
Huading Separator has over 60 years of tradition in mechanical separating technology. As China's leading manufacturer, our developments serve diverse industries including beverage, dairy, oils and fats processing, chemicals, , biotechnology, starch technology, marine engineering, energy, oil fields, and environmental technology. We develop customized centrifuges and complete process lines tailored to customer requirements.
Quality Standards
- JB/T 8103 standards - Chinese national standard of disc centrifuge
- 2006/42/EC (Machinery)
- 2014/35/EU (Low Voltage)
- 2014/30/EU (Electromagnetic Compatibility)
- ISO9001-2000 Quality Management System
Centrifugal Separation Technology
The disc stack separator separates solids and one or two liquid phases from each other in a single continuous process using extremely high centrifugal forces. Denser solids are forced outward against the rotating bowl wall, while less dense liquid phases form concentric inner layers. The interface position between liquid phases can be adjusted for maximum separation efficiency. The disc stack plates provide additional surface settling area, dramatically speeding up the separation process. This configuration enables continuous separation of various solids from liquids, with solids removal available continuously, intermittently, or manually depending on centrifuge type and application requirements.
2-Phase Separation Disc Stack Centrifuge
Separation occurs inside a rotating bowl where feed is introduced from the top via a stationary inlet pipe. After acceleration in the distributor, the feed enters the disc stack where liquid-solid separation takes place. The liquid phase moves through the disc stack to the center and is pumped out via a built-in paring disc. Solids collect in the periphery and are discharged intermittently through a hydraulic system that opens solids ports at the bowl periphery.
3-Phase Separation Disc Stack Centrifuge
Suspension is fed into the separator bowl from the top through a feeding pipe into the disc stack. The heavy phase and sludge move toward the bowl periphery while the light phase flows toward the center for pumping. Heavy phase is led over a top disc into a chamber where a paring device pumps it out. Solids collect in the sludge space and discharge intermittently via a hydraulic system that opens solids ports, with solids collected in the frame and exiting via a cyclone.
Self-cleaning disc stack centrifuges are divided into two types: purifiers for solids and two liquid phases, and clarifiers for solids and one liquid phase.
Why Choose Huading Separator
60+
Years Experience developing and manufacturing disc stack centrifuges
40,000+
Installations in more than 50 countries since 1954
100+
Centrifuge models to satisfy diverse customer demands
Global
References from worldwide food and pharmaceutical manufacturers
Certifications
All products pass rigorous inspection standards including CE and ISO certification with 100% quality assurance.
Manufacturing Capabilities
Packaging & Shipping
Package: Standard export carton packing
Delivery Time: 30-90 days after order confirmation, with exact delivery date determined by production season and order quantity
